Hermite Polynomial Hn(x) Table and Graph Calculator

Hermite Polynomial Hn(x) Table and Graph Calculator

Emerging AI Skill PRO

Enter Calculation

Formula

Hn+1(x)=2xHn(x)−2nHn−1(x),H0=1,H1=2xwhere{n=Orderxi=Start x+i·Stepi=0,1,…,Count−1\begin{gathered} H_{n+1}(x) = 2x\,H_n(x) - 2n\,H_{n-1}(x), \quad H_0 = 1,\ H_1 = 2x \\[1.5em] \text{where}\quad \left\{ \begin{aligned} n &= \text{Order} \\ x_i &= {{\text{Start }x}} + i \cdot \text{Step} \\ i &= 0,\,1,\,\dots,\,\text{Count} - 1 \end{aligned} \right. \end{gathered}
Usage stats

Advertisement

Results

Hermite polynomial order n = 3
51 points
first Hn(x) = -95, last Hn(x) = 95
i x Hn(x)
0 -2.5 -95
1 -2.4 -81.792
2 -2.3 -69.736
3 -2.2 -58.784
4 -2.1 -48.888
5 -2 -40
6 -1.9 -32.072
7 -1.8 -25.056
8 -1.7 -18.904
9 -1.6 -13.568
10 -1.5 -9
11 -1.4 -5.152
12 -1.3 -1.976
13 -1.2 0.576
14 -1.1 2.552
15 -1 4
16 -0.9 4.968
17 -0.8 5.504
18 -0.7 5.656
19 -0.6 5.472
20 -0.5 5
21 -0.4 4.288
22 -0.3 3.384
23 -0.2 2.336
24 -0.1 1.192
25 0 -0
26 0.1 -1.192
27 0.2 -2.336
28 0.3 -3.384
29 0.4 -4.288
30 0.5 -5
31 0.6 -5.472
32 0.7 -5.656
33 0.8 -5.504
34 0.9 -4.968
35 1 -4
36 1.1 -2.552
37 1.2 -0.576
38 1.3 1.976
39 1.4 5.152
40 1.5 9
41 1.6 13.568
42 1.7 18.904
43 1.8 25.056
44 1.9 32.072
45 2 40
46 2.1 48.888
47 2.2 58.784
48 2.3 69.736
49 2.4 81.792
50 2.5 95

Report an error on this page

What this calculator does

This tool evaluates the physicists' Hermite polynomial \(H_n(x)\) for a single fixed order n across a sequence of x values. It returns a table of \((x, H_n(x))\) pairs and draws the curve. Hermite polynomials appear throughout quantum mechanics (the energy eigenstates of the harmonic oscillator), probability theory, and numerical analysis (Gauss-Hermite quadrature).

How to use it

Enter the polynomial order n (a non-negative integer such as 0, 1, 2, 3, ...), the initial value of x, the increment (step between successive x values), and the number of repetitions (how many rows to generate). The i-th x value is $$x_i = \text{startX} + i \cdot \text{stepX}$$ for i = 0 to count-1. A negative increment produces a descending table; a zero increment repeats the same x.

The formula

These are the physicists' Hermite polynomials, satisfying the differential equation \(y'' - 2x \cdot y' + 2n \cdot y = 0\) and generated by \(\exp(2xt - t^2)\). We compute them with the stable three-term recurrence $$H_0(x) = 1, \quad H_1(x) = 2x, \quad H_{k+1}(x) = 2x \cdot H_k(x) - 2k \cdot H_{k-1}(x).$$ This avoids factorial overflow. Note these are not the probabilists' \(He_n(x)\), which use \(He_{k+1} = x \cdot He_k - k \cdot He_{k-1}\).

Advertisement
Recurrence relation tree showing how each Hermite polynomial is built from the two previous ones
The three-term recurrence builds each Hermite polynomial from the two preceding orders.

Worked example

For n = 3 the recurrence gives \(H_2(x) = 4x^2 - 2\) and \(H_3(x) = 8x^3 - 12x\). At \(x = -2.5\): $$8(-15.625) + 30 = -95.$$ At \(x = 0\) it is 0, and at \(x = 2.5\) it is +95. With startX = −2.5, stepX = 0.1 and 51 repetitions the table runs from \((-2.5, -95)\) through \((0, 0)\) to \((2.5, 95)\), tracing an odd-symmetric cubic-shaped curve.

FAQ

Which convention is used? The physicists' convention \(H_n\), where \(H_1(x) = 2x\). First few: \(H_0 = 1\), \(H_1 = 2x\), \(H_2 = 4x^2 - 2\), \(H_4 = 16x^4 - 48x^2 + 12\), \(H_5 = 32x^5 - 160x^3 + 120x\).

What if n = 0? \(H_0(x) = 1\) for every x, so the table and graph are a flat line at height 1.

Why do values explode for big n? Hermite polynomials grow extremely fast for large order and large \(|x|\); double precision can overflow beyond roughly 1e308. Keep n and the x range modest for sensible plots.

Overlaid graphs of the first few physicists' Hermite polynomials
Curves of H1 through H4 over a symmetric x-range, showing growing oscillation with order.
